Lenovo ThinkSystem SR570 7Y03A06ANA 1U Rack Server - 1 Xeon Gold 6242 2.80 GHz - 32 GB RAM - 12Gb/s SAS Controller
Specifications
| Core Specs | |
|---|---|
| Processor Type | Xeon Gold |
| Processor Model | 6242 |
| Number of Processors Installed | 1 |
| Number of Processors Supported | 2 |
| Graphics Controller Model | G200 |
| Standard Memory | 32 GB |
| Graphics Memory Capacity | 16 MB |
| Number of Solid State Drives | No |
| Number of Hard Drives | No |
| Chipset Manufacturer | Intel |
| Chipset Model | C622 |
| Features | |
|---|---|
| Security Features |
|
| Remote Management | Yes |
| RAID Supported | Yes |
| Hot Swappable Power Supply | Yes |
| Hot Swappable Bays | Yes |
| Intel Optane Memory Ready | Yes |
| Optical Drive Type | No |
| Ports & Connectors | |
|---|---|
| PCI Express Details | half-length Slot 3: PCIe 3.0 x8 or x16; low profile , Slot 1: PCIe 3.0 x8; low profile Slot 2: PCIe 3.0 x16 or ML2 x8; low profile or full-height |
| Total Number of USB Ports | 4 |
| Number of USB 2.0 Ports | 1 |
| Number of USB 3.0 Ports | 3 |
| Network (RJ-45) | Yes |
| Number of Network (RJ-45) Ports | 2 |
| VGA | Yes |
| Number of Total Expansion Bays | 4 |
| Number of 3.5" Bays | 4 |
| Number of LFF Bays | 4 |
| Total Number of Expansion Slots | 3 |
| Plug/Connector Type | C13/C14 |
| Dimensions & Physical Attributes | |
|---|---|
| Form Factor | Rack |
| Rack Height | 1U |
| Technical Specs | |
|---|---|
| RAID Levels | 0 , 1 , 5 , 6 , 10 , 50 , 60 , JBOD |
| Input Voltage | 120 V AC , 230 V AC |
| Number of Power Supplies Installed | 1 |
| Number of Power Supplies Supported | 2 |
| Processor Generation | 2nd Gen |
| Processor Core | Hexadeca-core (16 Core) |
| Processor Speed | 2.80 GHz |
| Cache | 22 MB |
| Memory Technology | TruDDR4 |
| Memory Clock Speed | 2.67 GHz |
| Number of Occupied Memory Slots | 1 |
| Error Checking | ECC |
| Signal Processing | Registered (Buffered) |
| Maximum Memory Supported | 1 TB |
| Ethernet Technology | Gigabit Ethernet |
| Controller Type | 12Gb/s SAS |
| Controller Model | 930-8i |
| Maximum Power Supply Wattage | 750 W |
| Software & Licensing | |
|---|---|
| Operating System Supported | Red Hat Enterprise Linux 7.6 , Red Hat Enterprise Linux 7.7 , SUSE Linux Enterprise Server 12 SP4 , SUSE Linux Enterprise Server 15 SP1 , SuSE Linux Enterprise Server 15 , Windows Server 2012 R2 , Windows Server 2016 , Windows Server 2019 , Red Hat Enterprise linux 7.4 , Red Hat Enterprise Linux 6.9 |
| Operating System | No |
| Compliance & Certification | |
|---|---|
| Energy Star | Yes |
| Environmentally Friendly | Yes |
| Packaging & Origin | |
|---|---|
| Package Contents |
|
| Warranty & Support | |
|---|---|
| Limited Warranty | 3 Year |
| Additional Warranty Information | Three-year customer-replaceable unit (CRU) and onsite limited warranty with 9x5 Next Business Day Parts Delivered |
| General Information | |
|---|---|
| Brand | Lenovo |
| Manufacturer | Lenovo Group Limited |
| Product Type | Server |
| Product Series | SR570 |
| Product Line | ThinkSystem |
| Product Model | 7Y03A06ANA |
| Manufacturer Website Address | http://www.lenovo.com/us/en/ |
